A90F Fingerpint POS Machine

Android POS A90F

A90F is a smart handheld POS terminal, this is a powerful functional mobile payment terminal with a high-definition multimedia color touch screen and has a fingerprint scanner. It supports various communication technologies such as 4G, WIFI, and Bluetooth. The operating system is Android 7.0 and adopts the security chip required by PCI. It recognizes all financial payment and consumption functions such as magnetic stripe card, contactless card, two-dimensional code drawing, and payment, etc.A90 POS comes in a sleek and attractive design, combines the full features of an Android tablet with a powerful payment terminal, and compatible with all leading intelligent technology.


Contactless
Ic Card
Magstripe
Wifi
Bluetooth

Features

Light weight and slim design

5.5" IPS color screen, 1280*720

Speed up work flow

Improve accuracy

High speed thermal printer

32 bit, Quad-Core

Card readers

5200mAh

Camera

Smart Applications

Coupon
VIP
Report
Invoicing
Top Up
Finance
Store
Order

Specifications

OS

Android 7.1
Secure operating system

Processor

32-bit Quad-Core
1.1Ghz application processor

Memory

RAM-1GB (optional 2GB)
R0M-9GB (optional 16GB)
External Flash: 32GB at maximum

Display

5.5 IPS screen, 1280*720
Capactive touchscreen

Communications

4G/3G/2G

Bluetooth

BT 4.1, BLE

WI-FI

B02, 11 bigin
2.4GHz, Optional 5GHz

Card Readers

Magnetic card reader
IC card reader
NFC reader

Keys

1 Power keys
1 Printer keys
3 Touch keys

Printer

High-Speed Thermal Printer
Paper Width: 58 mm
Diameter: 40 mm

Camera

2MP Front camera,
5MP Rear camera, auto focus, flashlight
1D/2D Barcode scan

Audio

Speaker
Buzzer
Microphone

Card Slots

2 SIM
2 PSAM
1 SD Card

Adapter

Input: AC 100-240V 50/60GHz 0.5A
Output: 5V/2A

Battery

Li-ion battery
3.6V/5200mAh

Indicator Lights

4 LED Indicators
1 Charging indicators

Dimensions

205*82*65mm
L*W*H

Weight

440g

Peripheral Ports

1 USB Type-C
1 Pogo Pin

Fingerprint

Mapro OX Sensor
Spatial resolution 508 DM
Image Size 256*360 Pixels
Image capture speed 5 FPS
Lowest FAR and FRR

GNSS

GPS/GLONASS/BelDou

Environmental

Operation temperature -10°C~50°C
Storage temperature -20°C~70°C
Relative humidity 5%~95%, Non-condensing

Certificates

PCI PTS 5.x, EMV Lt
EMV CL L1, Mastercard Paypass
Visa Paywave, JCB J/Speedy
Amex expesspay
Union Pay quickPass
Mastercard TQM, RuPay, PURE
RoHS, Anatel, BIS
FBI MV certified

Optional Configurations

Docking stations
3 Optional docking stations
Support charging, reflection scanning
Serial ports, ethernet ports, external USB ports
