Wireless Countertop POS Terminal V72

Wireless Countertop POS Terminal

V72
V72
V72
V72

V72 is the latest product innovation in the mobile payment market. The new model has a more modern and ergonomic design, as well as the ability to install a 1D/2D scanner for reading bar-codes. mupizo V72 is equipped with a bright 2.8-inch color TFT display, which provides excellent readability even in the sun. The terminal uses a GSM module, which can be supplemented with Wi-Fi to provide communication. mupizo V72 is a perfect solution for banks, shopping malls, hotels and delivery services.

Contactless
Ic Card
Magstripe
Barcode
Wifi
Bluetooth
Inquiry Brochure

Features

Light weight and slim design

2.8" Color Screen

Speed up work flow

Improve accuracy

32bit, ARM Secure Core SC300

Card Readers

2600mAh

Smart Applications

Coupon
VIP
Report
Invoicing
Top Up
Finance
Store
Order

Specifications

Operating System

VOS

Processor

32 ARM SecureCore Sc300

RAM

1 Mb(Optional 8MB)

ROM

16 Mb

Micro SD card

Up to 32 GB

Display specifications

2.8 Colorful / Touch Screen / 320x240

Keys

19 physical buttons

Card Readers

Magstripe Card / IC Card / NFC Card

Audio

Buzzer

Communication

GPRS / 4G / Wi-Fi

Peripheral ports

1 Power USB Type-C, USB OTG

Card slots

1 x PSAM / 1 x SIM

Printer

High-speed thermal printer / Paper Roll width is 58mm and Paper Diameter is 38mm

Indicator Light

4 LED indicators

Power Supply

AC Input:100V~240V, AC 50/60Hz; DC Output:5V/2A

Battery

Li-battery, 3.6V, 2600mAh

Dimensions

166 (L) x 80 (W) x 54 (H) mm

Weight

< 400 g

Environmental

Operating temperature ( -1 ⁰c ~ 5 ⁰c)
Storage temperature (-20⁰c ~70⁰c )
Operating humidity (5% ~ 95% non-condensing)

Certification

PCI PED 5.x / EMV Contact Level 1 / EMV Contact Level 2 / EMV Contactless Level 1 / Mastercard PayPass / VISA PayWave

Optional Configurations

Display

Resistive touch screen Electronic signature

Communications

WiFi 802. 11a/b/g/n, 2.4G / 4G

Camera

1D/2D Scanner
